SPECIFICATIONS:
Max Swing Over Bed 36.8"
Max Turning Diameter 25.5"
Max Tailstock Position 78.7"
Max Turning Length 81.2"
Travel Z /X 82.7"/ 13.6"
Rapid Traverse Rate X/Z 787/944 IPM
Tool Positions 12
Live Tool Positions 12
Hole Thru Spindle 5.1"
Spindle Nose A2-11
Spindle Speed Range 20-2400 RPM
Spindle Horsepower 40 HP
Live Tool Milling Speed 3000 Max RPM
Live Tool Milling Spindle Horsepower 12 HP
EQUIPPED WITH:
MSC-501 Control (Fanuc)
18" 3 Jaw Chuck
Tool Presetter
Tail Stock
4 Live Heads
Steady Rest
Chip Conveyor
