Specifications:
Travel (XYZ) 28.70” x 20.1” x 20.1”
Table Size 19.70” x 19.70”
Table Load Capacity 1,760 LBS
Spindle Speed 12,000 RPM
Spindle Taper HSK-63
Tool Changer Capacity 31 ATC
Rapid Traverse Rate 1968-X/Y 1575-Z IPM
Spindle Motor 24.7 HP
B Axis Head Tilt +160 to -180 Degrees
C Axis Index 360 Degrees
Equipped With:
FS-31iA5 w/ MAPPS Control
Chip Conveyor
Glass Scales
Renishaw Probing
Renishaw NC 4 Fixed Non-Contact Tool Measurement Laser
Manual Pulse Generator
