Specifications
| Product Location | Anaheim, CA |
| Swing Over Bed | 36.4" |
| Swing Over Front Cover | 29.7" |
| Max. Turning Diameter | 14" |
| Max. Turning Length | 27.7" |
| Bar Work Capacity | 3.1" |
| Y Axis Travel | 3.9"<+/-2 |
| Z-Axis Travel | 31.3" |
| Headstock 2 Travel B-Axis | 28.9" |
| Max. Spindle Speed, Main | 4,000 RPM |
| Max. Spindle Speed, Sub | 6,000 RPM |
| Thru Spindle Hole Dia., Main | 3.6" |
| Thru Spindle Hole Dial, Sub | 1.7" |
| Number of Tool Stations | 12 |
| Max. Rotary Tool Speed | 10,000 RPM |
| Rapid Traverse Rate X,Z,B | 1,181 IPM |
| Rapid Traverse Rate Y | 393.7 IPM |
| Rapid Traverse Rate C | 400 Min. |
| Approximate Weight | 13,640 lbs. |
Features
Mitsubishi M-730UM Control
10” Chuck (main) / 6” Chuck (sub)
Tool Presetter (main & sub)
Parts Catcher
Barfeed Interface Only
Chip Conveyor
All Available Manuals
Review 2015 DMG Mori NLX-2500SY/ 700 ***SOLD***.
